Citroen C5 Wagon

Citroen C5 Wagon 2.0 HDi 165 (Automatic)

Technical specifications, versions, and history for the Citroen C5 Wagon.

Back

Citroen C5 Wagon

2.0 HDi 165 (Automatic)

163ps
34.7kgf.m
208 km/hkm/h
10.2 s0-100 km/h

Engine & Performance

LocationFront
LayoutTransverse
CylindersInline-4
Displacement2.0 L (1997 cc)
ValvetrainDOHC
Valves per Cylinder4 per cylinder (16V)
Compression Ratio16.0:1
Engine NamePSA DW10 CTED4 (RHH)
FuelDiesel
AspirationVariable Geometry Turbocharger with Intercooler
Fuel SystemDirect Injection Common Rail
Power (ps)163 hp @ 3750 rpm
Torque34.7 kgf.m @ 2000 rpm (251 lb-ft)
Power-to-Weight Ratio10.07 kg/hp (22.51 lbs/hp)
Torque-to-Weight Ratio47.32 kg/kgf.m
Redline4500 rpm
TransmissionAutomatic, 6-speed
Transmission IdentificationAM6 (Aisin Warner TF-80SC)
Drive TypeFront-Wheel Drive (FWD)

Fuel Economy

City12.2 km/l (28.7 mpg)
Highway19.6 km/l (46.1 mpg)

Wheels, Brakes & Steering

Front SuspensionIndependent, Double Wishbone (Hydractive 3+)
Rear SuspensionIndependent, Multi-link (Hydractive 3+)
Front BrakesVentilated discs
Rear BrakesSolid discs
SteeringHydraulic
Turning Circle11.7 m (38.4 ft)
Front Tires225/55 R17
Rear Tires225/55 R17

Dimensions & Capacities

Length4829 mm (190.1 in)
Width1853 mm (73.0 in)
Height1491 mm (58.7 in)
Wheelbase2815 mm (110.8 in)
Drag coefficient0.31
Ground ClearanceVariable (Hydractive 3+) (0.1 in)
Approach Angle
Departure Angle
Cargo Volume505 L
Curb Weight1642 kg (3,620 lbs)
Fuel Tank Capacity71 L (18.8 gal)
Payload Capacity644 kg (1,420 lbs)

Informações Gerais

Body StyleStation Wagon
SegmentD (Large Cars)
SubsegmentD-W (Large Wagons)
Doors5
Model Years2009 - 2012
Manufacturing LocationFrance
Market SoldEurope
Emission standard
