Citroen C5 Wagon

Citroen C5 Wagon 2.2 HDi 200 (Automatic)

Technical specifications, versions, and history for the Citroen C5 Wagon.

Back

Citroen C5 Wagon

2.2 HDi 200 (Automatic)

204ps
44.9kgf.m
225 km/hkm/h
8.6 s0-100 km/h

Engine & Performance

LocationFront
LayoutTransverse
CylindersInline-4
Displacement2.2 L (2179 cc)
ValvetrainDOHC
Valves per Cylinder4 per cylinder (16V)
Compression Ratio16.0:1
Engine NamePSA DW12 C (4HL)
FuelDiesel
AspirationVariable Geometry Turbocharger with Intercooler
Fuel SystemDirect Injection Common Rail
Power (ps)204 hp @ 3500 rpm
Torque44.9 kgf.m @ 2000 rpm (325 lb-ft)
Power-to-Weight Ratio8.66 kg/hp (19.36 lbs/hp)
Torque-to-Weight Ratio39.35 kg/kgf.m
Redline4500 rpm
TransmissionAutomatic, 6-speed
Transmission IdentificationAM6 (Aisin Warner TF-80SC)
Drive TypeFront-Wheel Drive (FWD)

Fuel Economy

City12.2 km/l (28.7 mpg)
Highway20.4 km/l (48.0 mpg)

Wheels, Brakes & Steering

Front SuspensionIndependent, Double Wishbone (Hydractive 3+)
Rear SuspensionIndependent, Multi-link (Hydractive 3+)
Front BrakesVentilated discs
Rear BrakesSolid discs
SteeringHydraulic
Turning Circle11.7 m (38.4 ft)
Front Tires245/45 R18
Rear Tires245/45 R18

Dimensions & Capacities

Length4829 mm (190.1 in)
Width1853 mm (73.0 in)
Height1491 mm (58.7 in)
Wheelbase2815 mm (110.8 in)
Drag coefficient0.31
Ground ClearanceVariable (Hydractive 3+) (0.1 in)
Approach Angle
Departure Angle
Cargo Volume505 L
Curb Weight1767 kg (3,896 lbs)
Fuel Tank Capacity71 L (18.8 gal)
Payload Capacity600 kg (1,323 lbs)

Informações Gerais

Body StyleStation Wagon
SegmentD (Large Cars)
SubsegmentD-W (Large Wagons)
Doors5
Model Years2012 - 2015
Manufacturing LocationFrance
Market SoldEurope
Emission standardEuro 5
